    Blue C Section Roll Forming Machine , Cold Roll Forming Machine With Hydraulic Cutting

    Ask Lasest Price
    Brand Name : FEIXIANG
    Model Number : Full Automatic C Shape Purlin Cold Roll Forming Machine with Hydraulic cutting
    Certification : CE,ISO
    Payment Terms : Western Union, T/T, L/C, D/A, D/P, MoneyGram
    Supply Ability : 30 SETS ONE MONTH
    Delivery Time : 40 DAYS
    Price : Price pls consult with supplier
    • Product Details
    • Company Profile

    Blue C Section Roll Forming Machine , Cold Roll Forming Machine With Hydraulic Cutting

    Blue C Section Roll Forming Machine , Cold Roll Forming Machine With Hydraulic Cutting


    Specifications

    1. C purlin roll forming machine

    2. high precise and run throughly
    3. reliable quality with CE,BV,ISO certification
    4. professional service and engineer
    5. good reputation and trustable


    Model:C&U Type


    Configurations

    Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Body Of Roll Forming Machine, Electro-Motor, Hole-Punch Device ,Cutting Device ,Hydraulic Station ,PLC Control.

    Control System

    PLC Panasonic Inverter

    Main Frame

    350mm H-Beam

    Main Power

    15 kw

    Pump Power

    7.5kw

    Power Supply

    3Phase,380V,50Hz

    Forming Speed

    12-14m/min

    Hydraulic Pressure

    18-20MPa

    Forming Size

    80-300mm

    Feeding Thickness

    1.5-3.2mm

    Roller Station

    12 Stands

    Roller Diameter

    80mm

    Backboard Thickness

    18mm

    Chain Size

    66mm

    Cutter Standard

    Cr12

    Roller Standard

    Cr12

    Cr-Plating Size

    0.05mm

    Overall Size

    9500×1400×1350mm

    Total Weight

    6T


    All technical parameters can be changed,according to user's need.
